High Efficiency Model 40 Strain Wave Reducer

Key Features

• 3.64kg

• Less than 20 Arc Sec backlash

• Average input speed: 3000 r/min

• Maximum input speed: 4000 r/min
• Compact and Lightweight Design

• Reduction ratios: 50:1, 80:1, 100:1, 120:1

Specifications

Rated Parameters Table of LSN-40-XX-U-I series

Key Attributes of LSN-40-XX-U-I Strain Wave Reducer
Product	Model 40 Strain Wave Reducer
Material	Steel, Aluminum, Polyurethane, Bearings and Seals, Lubricants
Reduction Ratio	50:1 to 120:1
Backlash	Less than 20 Arc Sec
Average Input Speed	3000 r/min
Max Input Speed	4000 r/min
Design Life	15000 hours
Model	40
Weight	3.64 kg
Warranty	1 year
Application	Robotics, Aerospace, Industrial Automation

Applications

Semiconductor	Industrial Robots	Medical Devices
Huamnoid Robots	Aerospaces	CNC Machines

PDF Drawings Download

---

LSN-40-XX-U-I.pdf

Suzhou Giant Precision Industry Co., Ltd. is a technical-service enterprise specializing in keeping on researching core technologies and developing high precision transmission products. We mainly provide strain wave reducers, RV reducers, rotary actuator, planetary reducers, electric grippers.

Currently, our products have been widely used in a variety of industrial sectors, such as manipulator, industrial robots, CNC machine tool, printing equipment, textile machine, packaging machinery, non-standard automation, medical equipment, laser cutting, welding, automobile manufacturing, satellite communications, metal processing, pharmaceutical industry, etc.

Our mission is to adhere to our service philosophy, put customer value in our first place, to provide high-quality products, professional technical support and diverse services.
